What is the technical difference between silicone heating wire manufacturers and silicone heating wires!
Silicone heating pads are actually silicone heating wires, but each place has a different name. Guangdong or Zhejiang and other places are habitually called silicone heating wires, and they are used to calling them in Anhui, Shandong, Henan, Hebei and other places. For the silicone heating wire, the products are the same, and it is indeed easy to make people understand mistakes. Not only this product, but also carbon fiber heating wires and carbon fiber heating wires are the same.
Product Description:
Silicone heating film is a flexible electric heating film element assembled by high thermal conductivity insulating silica gel, high temperature resistant glass fiber cloth and metal heating film circuit.
The main features of silicone heating film products:
1. The silicone heating sheet has good flexibility and can make good contact with the heated object.
2. The silica gel heating sheet can be made into any shape, including three-dimensional shapes, and various openings can be reserved for easy installation.
3. The silica gel heating sheet is light in weight, the thickness can be adjusted in a wide range (the minimum thickness is only 0.5mm), the heat capacity is small, and it can reach a very fast heating rate, and achieve higher temperature control accuracy through temperature control.
4. Silica gel has good weather resistance and aging resistance. As the surface insulating material of the electric heating sheet, it can effectively prevent the surface of the product from cracking and enhance the mechanical strength.
5. The precise metal electric heating film circuit can further increase the surface power density of the silica gel heating element, improve the uniformity of the surface heating power, and prolong the service life.
6. The silica gel heater has good resistance to chemical corrosion and can be used in places with harsh environments such as dampness and corrosive gas.
7. Various specifications and sizes can be customized according to actual conditions of use.
Main section material:
(0.5-1.0mm) high temperature resistant silicone cloth + (0.03-0.1mm) nickel-chromium alloy sheet/copper foil + (0.5-1.0mm) high temperature resistant silicone cloth
Physical and electrical characteristics:
Voltage range: 1-380V AC/DC
Maximum operating temperature: 250℃
Optimal use temperature: ≤150℃
Insulation resistance ≥5MΩ
Compressive strength: 1500v/5s
Power deviation: ±8%
Product thickness 1.0-1.5mm (1.5-5mm can be customized)
Recommended power density 0.1-0.6W/cm2
