For fever films, I believe everyone has heard of it! There are many types and uses of it, now let's learn about aluminum foil heating sheets! What are the characteristics and applications of aluminum foil heating sheets?
The heating element is composed of a silicone insulated hair wire. Place the hair wire between two pieces of aluminum foil or hot melt on a single layer of aluminum foil. The foil heater has a self-adhesive bottom layer for quick and easy installation on the area where the temperature needs to be maintained. Foil heaters are made according to their needs and can therefore be sized to accommodate a variety of pages.
It is suitable for heating in the environment with rated voltage below 250V, 50-60Hz, relative humidity ≤90%, and ambient temperature of -30°C~+50°C.
Technical parameters:
1. Size: can be customized according to requirements;
2. Voltage: can be customized according to requirements;
3. Power deviation (resistance value deviation) ≤± 5%
4. Leakage current: at working temperature, leakage current ≤ 0.5mA;
5. Power deviation: the rated power under the rated voltage is +5%, -10% of the rated value;
6. Aluminum foil and heating wire bonding peeling strength: ≥ 2N/1min without peeling and falling off.
Aluminum foil heating sheet (aluminum foil heating sheet) application:
1. Refrigerator and freezer compensate for heating defrosting, air conditioning, rice cooker and small household appliances heating.
2. Heat preservation and heating of daily necessities, such as: toilet heating, bath foot tub, towel insulation cabinet, pet seat cushion, shoe sterilization box, etc.
3. Heating and drying of industrial and commercial machinery and equipment, such as: digital printer drying, seed cultivation, fungus cultivation, etc.
