The material of the mesh belt determines the functions conferred by the mesh belt. Different materials have different uses. Some mesh belts can be resistant to high temperatures, some are corrosion resistant, and some are resistant to oxidation. I have sorted out some data on the material of the mesh belt for your reference. I hope that the information compiled can learn more about the knowledge of mesh belts for new and old customers.
Material Chemical Composition (%) Maximum working temperature MAX WORK TEMP Characteristics
C Si Mn Ni Cr Mo
A3 ≤0.22 ≤0.3 ≤0.65---400° ordinary mesh belt
45# ≤0.50 ≤0.37 ≤0.80 ≤0.25 ≤0.25 500° Ordinary mesh belt
1cr13 ≤0.15 0.6 ≤0.6-12-14-650 ° Ordinary mesh belt
1cr17 ≤0.15 ≤0.6 ≤0.6-12-18-650 ° Ordinary mesh belt
304M ≤0.06 ≤1.0 ≤2.0 8.9-10.0 18-20-750° ordinary mesh belt
304L ≤0.03 ≤1.0 ≤2.0 9-13 18-20-750° Intergranular corrosion resistance
316 ≤0.08 ≤1.0 ≤2.0 10-14 16-18 2-3 750° Corrosion resistance
316L ≤0.03 ≤1.0 ≤2.0 12-15 16-18 2-3 750° resistant to intergranular corrosion
309S ≤0.08 ≤1.0 ≤2.0 12-15 22-24-950 ° Long-term high temperature resistance
310S ≤0.08 ≤1.5 ≤2.0 19-22 24-26-(domestic) 1000 °
(Imported) 1150 ° high temperature resistance and high temperature stretching
314 ≤0.25 ≤1.5-3.0 ≤2.0 19-22 23-26-(domestic) 1050 °
(Imported) 1250 ° Improve the antioxidant capacity on the basis of 310
CI20NI80 ≤0.15 ≤0.4-1.3 ≤0.7 75-78 20-23-1200 ° High temperature resistance, oxidation resistance
The above data is the characteristics of the content of the mesh belt material, including rare elements, working temperature, etc. It is hoped that the sorted mesh belt material data will help or guide more people in the choice of material .
