Description

Thermostat Sensor Temperature Switches KSD301 series snap-action use in a great variety of small home appliances, such as portable icebox, to provide temperature control or temperature protection. This can be divided into 7 sub-series: KSD301, KSD301R, KSD301G, KSD301GR, KSD301-SG, KSD301R-M, KSD301, GR-M

Specifications

Electrical Rating	AC 125V max 15A; AC250V 5A 10A 15A max 16A
Action Temperature range	0~280 degree
Recovery and action temperature difference	10 to 25 degrees, or according to client's request.
Temperature deviation	±3 / ±5 / ±10 degree or according to client's request
Circuit resistance	≤50mΩ (Initial value)
Insulation resistance	≥100mΩ (DC500V Normal State)
Dielectric Strength	AC50Hz 1500V / min, no breakdown blinding (Normal State)
Life cycle	≥100000 times
Contact type	Normally closed & Normally open
Scope of application	It is used as temperature control for household electric appliances and widely applied in coffee pots, automatic toasters, laminators, electric water pots, steam guns, steam irons, wind warmers, microwave ovens, water dispensers, etc.

Features

* Miniature size, easy to install

* Individually temperature calibrated and checked

* Positive make and break with snap action bimetal disc

* Repeatable temperature performance over life

* Available in metallic shell and plastic shell

* Temperature sensitivity for maximum design flexibility

* Wide selection of leads and imported Mylar insulating sleeves.

* Strict RoHS environmental standard implemented for each component

* Cadmium free silver-nickel alloy contacts

* Wide selection of trip off temperatures

* Low internal resistance: Below 50 milliohm

* Optional Normally Close type and Normally Open type

* High temperature resistant lead wire, customizable as per customer requirements
