Description

PTC Heating Element for Fan Heater using a PTC ceramic heating element and aluminum components.

It is composed of galvanized steel plate, stainless steel corrugated spring sheet, galvanized plate, single layer aluminum fins, PTC heating piece, double aluminum fins, nickel copper electrode terminal and PPS high temperature plastic electrode sheath. The product due to the adoption of the U-shaped corrugated fin and improve the heat dissipation rate and combines the advantages of both adhesive and mechanical, and give full consideration to the PTC heating element in a variety of heat, electricity, strong binding force, thermal conductivity, excellent heat dissipation, high efficiency, safe and reliable. The type PTC heater has the advantages of small thermal resistance, high heat transfer efficiency, and is a kind of automatic constant temperature and electric heater. And one of its prominent feature is the safety performance, that the case of the fan fault stop rotating, the PTC heater due to lack of sufficient heat, its power will automatically dropped sharply. At this time, the surface temperature of the heater maintain in around the Curie temperature (general in 250 DEG C), to produce such as electric heating tube type heater surface of the "red" phenomenon.

Application

Air conditioner, hot air curtain machine, dryer, dryer, dehumidifiers, air heater, automobile etc. need to provide warm air equipment.

Feature

Temperature rise rapidly, in case of the failure of the wind turbine can control the temperature, long service life

Wide voltage range, can be designed according to the needs of 12V-380V

Design is convenient, can be from small power to big power any design, shape can also be designed according to requirements

Not burning, safe and reliable

Production Pictures

Advantages

1. Heat quickly aluminum film is more compact, higher thermal efficiency.

2. Healthy and environmentally friendly adhesive bonding more health.

3. Long and durable, no oxidation, the use of life more than 10000 hours.

1. Types

Blowing type: insulated type with wave radiator, uninsulated type with wave radiator, insulated type with inserted foil radiator, insulated type with comb radiator.

Heater with fan: insulated type with fan, uninsulated type with fan.

Convecting type air heater.

2. Some appliances.

Blowing type: room heater, bathroom heater, air conditioner heater, drying room heater, clothes dryer, hand dryer, air conditioner system for electric car, discharging loader for battery.

Convecting type: moistureproof and dew proof for electronic equipments, heating for electronic controll case, room heater.

3. Notice in appliance.

Blowing type:

1)This type of PTC air heater need a fan to blow, usually the faster is the air blowing speed, the larger is the power;

2)When PTC is used in very low ambient temperature, it have to be special designed;

3)PTC heater do not be damaged without air blowing, but the power is very low;

4)The power could be adjusted by air blowing speed; or it could be adjusted by voltage; or changing the number of heaters.

5)The surface tempetature on heater would be higher without air blowing. A thermostat could be assembled on the heater, preventing the damage of the holde;

6)The surface temperature on dispersion plate is closed to the curie temperature, without air blowing; but the surface temperature on dispersion plate will be lower than the curie temperature very much, with air blowing;

Convecting type.

1) Heating power depends on assembling methods, direction of the heater;

2) Keep air flowing itself for heat could be diffused;

3) The heating power will be increased 2~4 times, when the heater is blowed;

4) The heating power will be increased, when the heater is assembled on a metal holder.
