Thermal Pipe Heating Jackets

Description

Thermal pipe heating jackets insulation have three to six layers, liner is high silica glass fiber cloth, stainless steel braided cloth, ceramic fiber cloth, glass fiber cloth or high-SI aluminum cloth, and insulating layer is ceramic or glass fiber or aerogel blanket, and the protection layer is silicone coated glass fiber cloth, teflon cloth or stainless steel braided cloth, which is water, oil, acid and alkali proof. The thickness is 5-150mm, which could be customized, temperature resistance could be as high as 1000 cent degree. Normal lifetime is more than 5 years. And the energy saving rate is 25% to 40%.

Types of thermal pipe heating jacket insulation

A) Cold insulation type

B) Low temperature insulation type (below 300ºC);

C) Standard type (300---600ºC).

D) High temperature insulation type (above 600 C).

Application

Molds and dies

Flange, Pipe, Valve

Exhaust Elbow

Heater exchanger

Exhaust pipe of engine

Any other applications needed to reduce heat loss

Barrel heater on injection molding machine, extruder etc.

Feature

Detachable steam pipes with flexible heat preservation and insulation, energy saving and consumption reduction, radiation resistance in high temperature workshops, many pipes, valves or equipment, the internal temperature of which is very high, if the material is not protected, Easy to test personnel burns or loss of heat, etc.

The heat-resistant insulation sleeve has better thermal properties than other polymeric materials, as well as the function of radiation resistance and heat insulation. It can prevent accidents, energy consumption and direct transfer of heat from the medium in the valve pipe to the surrounding area, thus causing the workshop temperature to be too high. Reduce the cost of cooling. moisture-proof, anti-oil, anti-weathering, anti-pollution, equipment service life.

Some Production Pictures

Custom Made Service hotline, see below:
